25G CWDM Fiber Optic Transceivers Laser Chip With Temperature Range -5-85C

Model Number : JCCE-xxx0

Place of Origin : BeiJing

Brand Name : JHBF

Certification : ISO9001,14000;18000

Packaging Details : 10pcs/bilster box
2bilster boxes(total 20pcs)/carton

Price : $5.00/pieces 1-9 pieces

Type : Fiber Optic Transceivers, DFB laser

Use : CRAN

Data Rate : 25g 10G

Transmission Distance : 10km

Wavelength : 1271~1371nm 1471~1571nm

Temperature : -5~85C

No. of Fiber : 2.

Contact Now

25G CWDM Fiber Optic Transceivers Laser Chip With Temperature Range -5-85C
25G CWDM DFB Laser Chip
JHBF JCCE-xxx0 seires 25G DFB laser chip is designed for high speed, high performance optical communication applications as well
as 100G Datacenter and 5G networking applications.
JCCE-xxx0 used 200um cavity length to optimize over temperature performances and better reliability.
Details Images
25G CWDM Fiber Optic Transceivers Laser Chip With Temperature Range -5-85C
25G CWDM Fiber Optic Transceivers Laser Chip With Temperature Range -5-85C
25G CWDM Fiber Optic Transceivers Laser Chip With Temperature Range -5-85C
Application
It can be used for 5G Fronthaul and Data Center, and can be used in 25G CWDM SFP28 and 100G CWDM4 optical transceivers.
Recommended Operating Environment
Parameter
Symbol
Conditions
Min.
Max.
Unit
Operating Temperature
Top
---
-5
+85
°C
Storage Temperature
TStorage
---
-40
+85
°C
Solder Reflow Temperature
STEM
10sec Max.
---
260
°C
Light Output Power
Po
CW
---
10
mW
Laser Reverse Voltage
Vr
---
---
2
V
Forward Current Transient (LD)
If
---
---
100
mA
Recommended burn-in conditions:100C, 100mA, 48 hours, and judgment criteria is +/- 10% change of key parameters.
Specifications
Parameter
Symbol
Conditions
Min.
Typ.
Max.
Unit

Threshold Current
Ith
CW, Tc = 25°C
CW, Tc = 70°C
CW Tc = 85°C
---
9
14
19
12

25

mA
Forward Voltage
Vf
CW, Iop = Ith+30mA
---
1.25
1.35
V
Series Resistance
Rs
CW, Iop = Ith+30mA
---
6
10
Ohm
Slope Efficiency
SE
CW, Iop = Ith+30mA
0.20
0.35
0.45
mW/mA
Side Mode Suppression Ratio
SMSR
CW, Iop = Ith+30mA, Tc= -40°C ~ +85°C
35
43
---
dB
Central Wavelength and Span
λ
CW, Iop=Ith+30mA, Tc= -20°C ~ +85°C
λ-6.5
λ
λ+6.5
nm
Peak Wavelength
λ
CW, Iop=Ith+30mA, Tc= 25°C
λ-4.0
λ
λ+2.0
nm
Wavelength Temp. Coefficient
Dλ/ DT
Top = -40°C ~ +85°C
---
0.09
---
nm/°C
Beam Divergence ^
(q^)
CW, Po = 5mW
---
32
---
degree
Beam Divergence//
(q//)
CW, Po = 5mW
---
22
---
degree
Bandwidth

BW
Iop= 40mA, Tc= 25°C
Iop= 60mA, Tc= 70°C
Iop= 60mA, Tc= 85°C

---
18
15
12

---

GHz
Rise/Fall Time (20%~80%)
tr/tf
Iop = Ith+30mA, Top=25C 20% ~ 80%
---
23
ps
Chip Dimensions(W x L x H)
200 x 200 x 100 (+/-15)
um
Laser Cavity
---
200
---
um
Order Information
Part Number
Product Description
JCCE-xxx0
25G CWDM DFB laser chip ,-5~85°C,(xxx=271, 311, 331, 351, 371, 471, 491, 511, 531, 551, 571 represent 1271nm,1311nm,1331nm,
1351nm, 1371nm, 1471nm, 1491nm, 1511nm, 1571nm)
